Big fat shaped pleated filter
=== Performance characteristics ===
First, the polyester fiber filter material folded filter material, the core columns, cover the overall integration and good sealing
Second, the filtration area, a wide range of filtration precision, low differential pressure, flux and pollutant carrying a large amount of long service life
Third, the widely used, cheap
=== Should use ===
The HCDP big fat shaped pleated filter chemical agents, the plating liquid filtration, solvent and pharmaceutical pre-filter, industrial water purification, swimming pool filtration
- ===Common specifications===
| 過(guo)濾(lv)精度 | 5μm, 10μm, 20μm, 30μm, 50μm | 水流(liu)量-壓力差特性 (10"濾芯) |
| 濾芯(xin)長度 | 10", 20", 30" |
|
| 濾芯外徑(jing) | Φ115mm | |
| 濾芯內徑 | Φ28mm | |
| 過濾面(mian)積(ji)/10"長度 | 1.9m2 | |
| 最高工作溫度 | 45oC (壓差(cha)0.12MPa時) | |
| 最高工(gong)作壓力 | 1.0MPa@25oC | |
| 正向耐壓差 | 0.4MPa@25oC | |
| 反向耐壓差(cha) | 0.05MPa@25oC | |
| 接口型(xing)式 | 平面壓入(ru)式 | |
| 端蓋材(cai)料 | 聚(ju)氨酯(zhi) |
A case of specifications, structural change, the latest data provided by the Company shall prevail
Two companies to accept the order of the non-sheet specifications of filter products
